In the chemical, pharmaceutical and other industries, N,N-Dimethylformamide (DMF), known as a high-performance “universal solvent,” is widely used in synthetic reactions and process cleaning. However, its wastewater—characterized by high concentration, high toxicity, high salinity, high boiling point, and poor biodegradability—has long been a major environmental challenge.

Traditional treatment methods have significant drawbacks: high-temperature distillation consumes enormous energy, easily causes coking and toxic byproducts, results in low recovery, and can decompose DMF; incineration is expensive, wastes valuable resources, and generates serious secondary pollution. While conventional extraction equipment is inefficient, struggling to meet the demands of continuous, large-scale production.

As a professional developer and manufacturer of centrifugal extraction equipment, Zhengzhou Tiei Extraction has specialized in liquid–liquid separation for many years. CWL-M series centrifugal extractor, coupled with integrated process solutions, adopts a “high-efficiency extraction + resource recovery + green and low-carbon” approach, effectively solving the challenges of DMF wastewater treatment and helping enterprises achieve both environmental compliance and economic benefits.

Core Process of Centrifugal Extraction for DMF Wastewater

Centrifugal extraction is a physical separation method. By adding specific extractants (e.g., chloroform, dichloromethane) to the wastewater, the difference in DMF partition coefficients between the extractant and the aqueous phase enables rapid separation and enrichment under centrifugal force. A complete and efficient DMF recovery system typically involves the following key stages:

1.Pre-treatment: Wastewater first passes through screens, flocculation-sedimentation, and high-efficiency dissolved air flotation (DAF) to remove suspended solids (SS) and colloids, preventing emulsification or equipment clogging during subsequent extraction.
2.Centrifugal extraction stage: The CWL-M series centrifugal extractor uses high-efficiency extractants such as chloroform or dichloromethane. The pre-treated wastewater and extractant enter the centrifuge at optimized ratios. Through 2–5 stages of counter-current extraction, DMF is efficiently transferred from the aqueous phase to the organic phase.
3.Solvent recovery and resource utilization: The DMF-laden extractant undergoes vacuum distillation for purification. Chloroform or dichloromethane is recovered at >98% and reused; DMF purity reaches 99.2%–99.5%, suitable for direct reuse in the production line. The raffinate is sent to biological treatment for further removal of residual organics, achieving compliant discharge or reuse.

This process realizes waste minimization, detoxification, and resource recovery of DMF wastewater, creating a complete closed-loop treatment system.

Why Choose CWL-M Centrifugal Extractor

Compared with traditional batch reactors, extraction columns, or mixer settlers, the CWL-M centrifugal extractor demonstrates overwhelming advantages in DMF wastewater treatment:

1.Revolutionary separation efficiency
Ultra-fast separation: Phase separation under centrifugal force takes less than 1 minute, 3–10 times faster than distillation.
High mass transfer efficiency: Micro-droplet technology enhances mass transfer; single-stage efficiency is 90%–95%, and multi-stage counter-current recovery exceeds 98%, far outperforming traditional processes (75%–80%).
Wide capacity range: Single units can handle 0–120 m³/h, suitable for small, medium, and large-scale wastewater treatment needs.

2.Low-carbon, energy-saving, and reduced operating costs
Ambient temperature operation: Extraction occurs at 20–30 °C, avoiding DMF decomposition and coking, and preventing toxic gases such as dimethylamine, ensuring zero secondary pollution.
Ultra-low energy consumption: Total energy use is only 1/5–1/3 of traditional distillation; steam consumption is reduced by over 65%, cutting treatment costs per ton of wastewater by 40%–64%.
Minimal solvent loss: Fully enclosed design reduces extractant volatilization by 30%, resulting in very low annual replenishment.

3.Robust construction and reliable operation
Corrosion-resistant: Wetted parts are made of 316L stainless steel and fluoropolymers, resisting pH 0.5–14 corrosive wastewater. Optional features include nitrogen protection, nitrogen sealing, and online oxygen monitoring, ensuring long-term stability in saline wastewater.
Leak-free design: Overhung structure with no bottom bearings or mechanical seals eliminates leakage risk and minimizes maintenance.

4.Compact footprint and intelligent automation
Space-saving: Modular and compact, occupying only 40% of the area of traditional extraction columns or distillation units, saving plant space.
Fully automated: Integrated PLC control monitors and automatically adjusts speed, ratios, and flow in real time, enabling 24/7 continuous operation with minimal labor.

Application Cases

Case 1: DMF Wastewater Treatment at a Pesticide Chemical Company

Pain points: The company produced 80 tons of DMF wastewater per day, with a concentration of 12%–15%. The original evaporation process had a recovery rate of only 78%, high energy consumption, severe DMF decomposition, and annual operating costs exceeding 4 million CNY.
Solution: Implemented a CWL250-M centrifugal extractors with 3-stage counter-current extraction + distillation.
Operational results:
DMF recovery rate increased to 96.5%, recovering approximately 1,200 tons of DMF annually.
Regenerated DMF purity reached 98.5%, reused in production, generating annual revenue exceeding 9 million CNY.
Total energy consumption reduced by 65%, saving 2.8 million CNY in annual operating costs.

Case 2: DMF Wastewater with Initial 30% Concentration, Daily Treatment 30 Tons

Solution: Applied a CWL350-M centrifugal extractors with 4–5 stage counter-current extraction.
Operational results:
DMF concentration in treated wastewater <0.1%, recovered DMF purity >99.5%, water content <0.05%, meeting reuse standards.
Compared with conventional biological/SBR processes, treatment efficiency increased by 300%, operating costs reduced by 60%, and footprint reduced by 70%.
Customer feedback: “Payback achieved within three months,” with extractant loss 40% lower than expected.

DMF wastewater treatment is no longer just an environmental burden for enterprises—it can be transformed into a new core profit growth point. Zhengzhou Tiei, leveraging its leading CWL-M series centrifugal extraction technology and mature DMF recovery processes, has successfully provided solutions to dozens of chemical, pharmaceutical, and textile companies, achieving “environmental compliance + resource recovery + cost reduction”.

Choosing our centrifugal extraction technology means selecting the most efficient, low-carbon, and cost-effective solution for DMF wastewater treatment, helping your enterprise seize the green development advantage under strict environmental regulations and achieve sustainable, high-quality growth.
